Parameter | |
| Tube diameter | 50-180mm |
| Tube length | 800-5000mm |
| Speed | 3-8M/Min |
| Quantity of abrasive band | 12Pcs |
| Way of grinding | Shaftless, continuous feeding |
| Way of load/unload | Auto/Pneumatic |
| Power supply | Custom |
| Operator | 1Person |
| Power of main engine | 5.5KW*6 |
| Power of air blower | 5.5KW |
| Power of feeding motor | 0.37KW*6 |
| Interver | YASKAWA |
| Dimension(L*W*H) | 9000*2500*1600mm |
| Weight | 3000KGS |
Use:
To make surface of tubes smooth and perfect.
Feature:
1.Grinding, waxing and polishing to become integrated, so the tubes can be able to process at the same time.
2.Delta PLC controller, touch screen in both English and Chinese, easy to operate.
3.Speed of giving tube can be controlled by Interter ,Auto load and unload
