Feature：
1、Using Servo system locating, High precision ball screw transmission, cutting resolution ratio up to 0.01mm.
2、Plc control, colorful touch screen operation.
3、Error auto detecting and warning.
4、Suitable for cutting big quantity and short length OR frequently changing cutting length
5、Cutting sensor, to protect damage of shaft.
6、Regularly auto lubricating system, save labor and lubrication oil etc.
Parameter | |
| Cutting length | Max 3000mm |
| Cutting diameter | 50-200mm |
| Cutting knife | 1Pc |
| Cutting speed | 25M/MIN |
| Cutting way | Tube spinning, shaft not |
| Load/unload way | Manual |
| Fixing way | Auto chuck |
| Operator | 1Person |
| Knife feeding way | Pneumatic cutting |
| Speed adjust control | Converter |
| Input power | Custom |
| Cutting thickness | 1-15mm |
Size（mm） | |
| Main size:L*W*H : | 3400mm*1500mm*1550mm |
| Total weight | 3000KGS |
| Engine power | 5.5KW |
| Revolving speed | 300-1000r/min |
| Carriage moving power | 1.3KW Yaskawa servo motor |
Control system | |
| PLC Control | Delta |
| Man-machine interface | Weinview6070 |
| Program version | JS-A5-1 |
| Actuator | CHNT |
| Signal component | OMRON |
| Pneumatic component | AIRTAC |
| Servo motor | YASKAWA |
| Move screw | TAIWAN SHANGYIN |
| Move track | TAIWAN SHANGYIN |
Enclosed equipment | |
| Cutting knife | 2Pcs |
| Application | 1SET |
