Function:

"E" series of paper tube machine ,designing idea: simple、compact、stable.

Standard for making paper tube 3”（ID76.5), Max wall thickness under 8MM, biggest tube ID can up to 200MM.

Use:

Chemical Fiber paper tube、All kinds of packaging paper can, All kinds of small industrial paper core.  model can produce spiral paper tube with gluing,winding,cutting together on.



Features:

1. Main structure made by thicker steels which are finished  by processing of re-cutting and welding,  make machine much more stable and strong.

2. Main transmission adopt gear speed cut, low-noise, low-heating, high revolution, high torque.

3. Main motor adopt Vectorial high torque inverter speed adjusting.

4. Equipped with Hydraulic device to adjust belt tension, with belt tension sensor and belt angle sensor, both can be adjusted automatically.

5. Equipped with synchronous cutting system, cutting table adopt high precision ball screw and high performance server motor drive.

6. Equipped pulse length fixation control, cooperated with front feedback compensation function, can make sure the same length in different producing speed.

7. Adopt double PLC control systems, IO output control and functional operation control separately, to increase cutting reaction speed, cutting length is much more accurate.

8. Equipped with new control panel and big size colorful main machine touching interface .

9. with multi functional bottom paper feeding device, will stop once paper break.

10. Equipped with integral paper reel stand, glue stand, paper feeding assembly, all are electrical control.

11. Design of modularization electric layout makes use、maintaining and repairing more convenient and scientific.

---
